10kA Miniature Circuit Breaker, 1-63A, 1P+N to 4P
Multi-pole MCB with B/C/D tripping curves, 10kA breaking capacity, suitable for AC 230/400V distribution systems.
AC 230/400VRated Voltage
1, 2, 3, 4, 6, 10, 13, 16, 20, 25, 32, 40, 50, 63 ARated Current
1P+N, 2P, 3P, 3P+N, 4PPole Configuration
10kA (Icn) / 7.5kA (Ics)Breaking Capacity
Product Overview
Multi-pole MCB with B/C/D tripping curves, 10kA breaking capacity, suitable for AC 230/400V distribution systems.
Key Features
- Model Number: RTSXD01
- Rated Voltage: AC 230/400V
- Rated Current: 1, 2, 3, 4, 6, 10, 13, 16, 20, 25, 32, 40, 50, 63 A
- Pole Configuration: 1P+N, 2P, 3P, 3P+N, 4P
- Breaking Capacity: 10kA (Icn) / 7.5kA (Ics)
Available Models / Configurations
| Model | Rated Current | Pole Configuration |
|---|---|---|
| RTSXD01 | 1, 2, 3, 4, 6, 10, 13, 16, 20, 25, 32, 40, 50, 63 A | 1P+N, 2P, 3P, 3P+N, 4P |
Technical Specifications
| Model Number | RTSXD01 |
| Rated Voltage | AC 230/400V |
| Rated Current | 1, 2, 3, 4, 6, 10, 13, 16, 20, 25, 32, 40, 50, 63 A |
| Pole Configuration | 1P+N, 2P, 3P, 3P+N, 4P |
| Breaking Capacity | 10kA (Icn) / 7.5kA (Ics) |
| Mounting Method | 35.5mm DIN Rail / Panel Mount |
| Standards | IEC 60898-1; IEC 60947-2 |
Applications
The supporting image shows a general application environment and does not depict an exact installed configuration.
Residential
Confirm that the selected model and documented ratings match the application requirements.
Commercial
Confirm that the selected model and documented ratings match the application requirements.
Industrial distribution
Confirm that the selected model and documented ratings match the application requirements.
Information to Confirm for Selection
Confirm the exact model, documented ratings, quantity and application before quotation.
Send the required ratings, model reference, quantity and destination country. We will confirm compatibility and availability before quotation.
FAQ
What pole configurations are available for this MCB?
Available in 1P+N, 2P, 3P, 3P+N, and 4P configurations to suit different installation needs.
